DeepEye DE3468D
DeepEye DE3468D
A dual-frequency side-scan sonar combining 340 and 680 kHz channels. The lower-frequency channel supports broader seabed coverage, while the higher-frequency channel is suited to closer inspection and habitat work.
Technical specifications
| Frequency | 340 / 680 kHz |
|---|---|
| Horizontal beam | 0.9° / 0.5° |
| Vertical beam | 60° / 60° |
| Range setting | 25–200 m / 10–100 m |
| Range resolution | 1.5 cm / 1 cm |
| Maximum operating depth | 100 m |
| Length / diameter | 850 mm / 60 mm |
| Weight in air / water | 9 kg / 6.7 kg |
| Interface | RS485 |
Values above refer to the documented DE-series configuration in the retained technical datasheet. Confirm the supplied configuration for a new system.
Deployment
The current DeepEye family can be used with a manual cable drum or a winch. Deep Vision describes practical deployment to about 60 m with its standard cable arrangement and towards 100 m with a winch. These deployment figures are distinct from the historical towfish pressure rating below.
